Optical Lens

Optical Lenses Optics

We offer concave, convex, spherical, cylindrical, and custom lenses with select focal lengths from 33-7500 mm. Our optical lens are made from fused silica, CaF2, MgF2 and more material options. We also offer Deep UV to Near-IR coatings.

Product Selection
Plano-Convex Lenses

Plano-Convex Lenses

Double-Convex Lenses

Double-Convex Lenses

Plano-Concave Lenses

Plano-Concave Lenses

Double-Concave Lenses

Double-Concave Lenses

Cylinder Lenses

Cylinder Lenses

Laser Lenses

Laser Lenses

UV Lenses

UV Lenses

Spherical Lenses

Spherical Lenses

IR Lenses

IR Lenses

Custom Optical Lenses

Our technical team will review your optical drawing or custom specifications and provide a quote.   Typically we offer:

Spherical Lens

  • Optical Size: 3 to 250 mm
  • Radii: 3mm to 7.5m, +/- 0.1%
  • Irregularity: 1/40λ
  • Surface roughness: 5Ǻ
  • Surface: 10/5 Laser Quality (scratch/dig)
  • Anti-reflective coating, R < 0.20%
  • AOI: 0-60 deg

    • Cylindrical Lenses

  • Size:   L: 5 – 150 mm;  W: 5 – 100mm
  • Radii: 20mm – 1m, +/- 0.1%
  • Surface irregularity: 1/4λ per 10mm on length and 1/2λ per 10mm on width
  • Surface roughness: 5Ǻ
  • Anti-reflective coating, R < 0.25%
  • Surface quality: 20/10 Laser (scratch/dig)
  • Select cylindrical lenses with 20mm – 1m, +/- 0.1% radii available

    • Spherical & Cylindrical Lenses

    Alpine Research Optics offers extensive lens manufacturing capabilities with decades long experience polishing all types of optical glasses, fused silica and crystalline materials including mgf2 lens and caf2 lens. We choose the best process technology to ensure such specifications for spatial frequency or low surface roughness on a given substrate are optimized to achieve the maximum optical performance. Lens truncation, angle, steep or long radii – we likely have in place the best practice for timely and efficient production.  Augmented by the capabilities of our sister company PFG Precision Optics, we have a vast library of test plates and many Verifire Zygo interferometers, complete with a variety of reference spheres and flats.

    We are one of the best ophthalmic lenses manufacturers in USA. We provide optical lensing mirrors in the glass optical lenses industry. So what is optical lens types? There are many options but generally we differentiate convex vs concave lens. Company ARO corp is a leading concavo convex lens factory that also makes Caf2 cylindrical lens focal length glass used for manufacturing of lenses. The optimal lens chief ray angle is the ray from an off-axis object point going through the center of the aperture stop of an optical lensing equation. If you are looking for convex lens vs concave lens supplier (concave lens convex lens factory) we are able to help! ARO surface plastic ir lens material and flat convex lens.

    Laser Lenses

    Laser lenses are designed to focus collimated light from laser beams. Laser lenses can come in a variety of designs such as laser generator lenses, aspheric lenses, cylinder lenses, and PCX lenses. A laser lens can focus light into several configurations like rings, points, lines, and more. We have an array of lens designs to choose from in many wavelength ranges.

    We have particular expertise in producing the following optical lense types:

    • Solid state are specifically designed to deliver high peak power damage threshold and low scatter, without sacrificing mechanical durability.
    • Excimer laser lens provide excellent mechanical durability, high pulse count lifetime and transmission, even at deep UV wavelengths.
    • Ultrafast lenses that possess the optimum combination of broad spectral bandwidth, minimum group velocity dispersion (GVD), low scatter, and peak pulse power damage resistance.

    Optical Lens Manufacturing

    At Alpine Research Optics, we have been creating optical lenses that can be used in a variety of applications and industries for over 30 years. They can be composed of one or many elements and can serve in very different areas. We are proud to create research lenses, optical components for use in imaging industry, medical, and even defense. As light passes through the lens, it is directly influenced by the profile of the lens optic. Additionally, material selection is crucial. So, we are engaged in the creation of a range of optical lenses. It includes wholesale convex lens manufacturing such as Plano and Double-Convex Lenses. Also, we offer laser 303 lens, double and plano-concave, cylinder, spherical, IR lenses, UV lenses, and more. We are one of the top industrial lens manufacturers USA that offers one of the largest inventories of optical lenses in the world.

    optical plastics custom lens design

    We use the latest custom optical lenses fabrication technology and mechanical engineering to ensure the best end product. ARO optic lens supplier values our technological approach, and thanks to new technologies we are able to produce large volumes. Our optic lense optics are used daily in a wide variety of fields, from medicine to security and military needs. It is important to us that our products perform optimally, whether you buy plano-convex lenses or fused silica cylindrical lens. Lense we produce undergoes strict quality control at the stage of creation so that we can ensure each of our products meets the required standards. When buying our products, you can be sure that our optical lenses will 100% fulfill their intended functions. At the same time, our team of professionals is always ready to advise you on the product you need in your specific situation. We will select the necessary optical lenses for you to precisely accomplish your application and achieve your goals.
